Features
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification��so all you have to worry about is where your e-bike will take you next.
Specs
Frame | 6061-T6 aluminum w/ patented Flat Foot Technology |
---|---|
Fork | Alloyhydroformed |
Hub front | Alloy low-flange w/6-bolt disc, 32h, 12mm thru-axle |
---|---|
Skewer front | Alloy thru-axle, 12mm x 143mm |
Hub rear | Alloy low-flange w/6-bolt disc, 32h, 12mm thru-axle |
Skewer rear | Alloy thru-axle, 12mm x 174mm |
*Rim | Size:M Alloy double walled 27.5''x32h |
Size:M Alloy double walled 27.5''x2h |
|
Tire | Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40'' |
Battery | Bosch PowerTube 500Wh |
---|---|
Charger | Bosch standard 4A, 100-240V |
Computer | Bosch Kiox with Anti-theft solution |
Motor | Bosch Active Plus, 250 watt, 50 Nm, 20mph or 32km/h |
Shifter | Shimano Alivio M3100, 9 speed |
---|---|
Rear derailleur | Shimano Alivio M3100, long cage |
*Crank | Size:M ProWheel alloy, 170mm length |
Size:M Forged alloy 170mm, Bosch type |
|
Chainring | Steel 40T w/alloy guard |
Cassette | Shimano HG200, 11-36, 9 speed |
Chain | KMC E9T EPT anti-rust |
Pedal | Resin platform w/grip tape tread |
Saddle | Selle Royal Essenza Plus |
---|---|
Seatpost | Alloy suspension post 27.2x400mm, 40mm travel |
Handlebar | Alloy custom bend |
Grips | Electra Vale custom ergo Kraton w/alloy locking collars |
Stem | Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length |
Headset | FSA e2 integrated |
Brake | Tektro hydraulic disc |
*Brake rotor | Size:M Tektro, 6-bolt, 180mm |
Size:M Tektro, 6-bolt, 160mm |
|
Rotor size | Front: 180mm, rear: 160mm |
*Light | Size:M Spanninga Axendo XE, LED, headlight |
---|---|
Size:M Spanninga Presto XE, LED, taillight |
|
*Kickstand | Size:M Adjustable length alloy kickstand |
Size:M Alloy, rear mount |
|
Cargo rack | Rear MIK compatible rack |
Extras | Painted chainguard, ring lock mounts, stainless steel and anti-rust hardware, and reflective decals on the frame and fork |
Weight | M - 24.45 kg / 53.91 lbs |
---|---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
