Features
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification��so all you have to worry about is where your e-bike will take you next.
Specs
Frame | 6061-T6 aluminum with patented Flat Foot Technology |
---|---|
Fork | Hi-ten steel unicrown, straight/tapered leg |
Skewer front | 100x5mm QR |
---|---|
Rim | Alloy double wall, 36h |
Tire | 26x2.35'' balloon |
Battery | 250Wh, integrated in down tube |
---|---|
Charger | 2A, 42V output, 100V-240V AC input |
Computer | LED display |
Shifter | Shimano Tourney Revo 7-speed twist with optical gear display |
---|---|
Rear derailleur | Shimano Tourney TY300 |
Chainring | Forged alloy 170mm, 42t chainring |
Bottom bracket | Torque sensor, threaded, 122.5mm spindle |
Cassette | 7-speed freewheel 14-34t |
Chain | KMC Z7, 7 speed |
Saddle | Ergonomic w/shock-absorbing elastomers |
---|---|
Seatpost | Alloy 27.2�300mm |
Handlebar | Alloy custom bend 25.9'' width/4'' rise |
Grips | Comfort kraton |
Stem | Forged alloy 25.4mm quill, 80mm extension |
Headset | 1 1/8'' steel threaded/semi-integrated |
Brake | Mechanical disc, 180mm rotor |
Brake lever | Alloy, 3-finger |
*Light | Size:M Spanninga, Kendo XE, LED, headlight |
---|---|
Size:M Spanninga Pixeo, LED, taillight |
|
Kickstand | Alloy, rear mount |
Weight | 20.91 kg / 46.1 lbs |
---|---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
