Features
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification��so all you have to worry about is where your e-bike will take you next.
Specs
Frame | 6061-T6 aluminum with patented Flat Foot Technology |
---|---|
Fork | Hi-ten steel unicrown, straight/tapered leg |
Hub front | Alloy low-flange w/CenterLock disc brake, 36h |
---|---|
Skewer front | 100x5mm QR |
Hub rear | Shimano Nexus 5-speed internal w/center lock disc brake 36h |
Spokes | 14g stainless steel, black |
Tire | Schwalbe Fat Frank 26x2.35'' balloon w/puncture-resistant Kevlar Guard casing |
Battery | Bosch PowerPack 400Wh |
---|---|
Charger | Bosch standard 4A, 100-240V |
Computer | Bosch Purion |
Motor | Bosch Active Plus, 250 watt, 50 Nm, 20mph or 32km/h |
Shifter | Shimano Nexus 5-speed twist w/optical display |
---|---|
*Crank | Size:26" wheel ProWheel alloy, 170mm length |
Size:26" wheel Forged alloy 170mm |
|
Cassette | Shimano 30t |
Chain | KMC Z1EHX nickel plated |
Pedal | Alloy platform w/non-slip rubber tread |
Saddle | Ergonomic w/shock-absorbing elastomers |
---|---|
Seatpost | Alloy micro-adjust 27.2x400mm |
Handlebar | Alloy custom bend 25.9'' width/4'' rise |
Grips | Ergo-shaped hand-stitched leatherette |
Stem | Forged alloy 25.4mm quill, 80mm extension |
Headset | 1 1/8'' steel threaded/semi-integrated |
*Brake | Size:26" wheel Tektro hydraulic disc brakes |
Size:26" wheel Tektro hydraulic disc |
|
Brake rotor | Shimano RT10, centerlock, 180mm |
Rotor size | Front/rear: 180mm |
*Light | Size:26" wheel Spanninga, LED, taillight |
---|---|
Size:26" wheel Spanninga, LED, headlight |
|
Kickstand | Alloy double leg |
Extras | ABUS frame lock, reflective battery decal, painted chainguard, internal cable routing, and stainless steel and anti-rust hardware |
Weight | 25 kg / 55 lbs |
---|---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
