Features
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification��so all you have to worry about is where your e-bike will take you next.
Specs
Frame | 6061-T6 aluminum with patented Flat Foot Technology |
---|---|
Fork | Hi-ten steel unicrown, straight/tapered leg |
Hub front | Alloy low-flange w/6-bolt disc, 36h, nutted |
---|---|
Hub rear | Hyena hub motor w/6-bolt disc, 36h, nutted |
Rim | Alloy double walled 27.5''x36h |
*Spokes | Size:M 13g stainless steel, black |
Size:M 14g stainless steel, black |
|
Tire | 27.5x2.35'' balloon |
Battery | 250Wh, integrated in down tube |
---|---|
Charger | 2A, 42V output, 100V-240V AC input |
Computer | LED display |
Crank | Forged alloy 170mm, 42t chainring |
---|---|
Bottom bracket | Torque sensor, threaded, 122.5mm spindle |
Cassette | 16T freewheel |
Chain | KMC S1 |
Pedal | Resin platform w/non-slip tread |
Saddle | Electra custom Kakau Go! |
---|---|
Seatpost | Alloy 27.2�400mm |
Handlebar | Electra caf茅 |
Grips | Electra hand-stitched |
Stem | Forged alloy 25.4mm quill, 80mm extension |
Headset | 1 1/8'' steel threaded |
Brake | Mechanical disc, 180mm rotor |
Brake lever | Alloy, 3-finger |
*Light | Size:M Spanninga, Kendo XE, LED, headlight |
---|---|
Size:M Spanninga Pixeo, LED, taillight |
|
Kickstand | Alloy, rear mount |
Weight | 21.68 kg / 47.8 lbs |
---|---|
Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
