Features
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification��so all you have to worry about is where your e-bike will take you next.
Specs
Frameset
- Frame
- 6061-T6 aluminum w/hydroformed top tube, patented Flat Foot Technology
- Fork
- Hi-ten steel unicrown
Wheels
- Front hub
- Alloy low-flange w/center lock disc brake 36h
- Rear hub
- Shimano Nexus Inter-5E 5-speed internal
- Rims
- Anodized alloy 26"�36h
- Tires
- Vee Rubber Speedster 26�2.8"
Drivetrain
- Shifters
- Shimano Nexus 5-speed twist w/optical display
- Crank
- Forged alloy 170mm, Bosch type, 38t chainring
- Cassette
- 30t
- Chain
- KMC Z1EHX nickel plated
- Pedals
- BMX alloy platform
Components
- Saddle
- Retro leatherette dual spring
- Seatpost
- Alloy micro-adjust 27.2x400mm
- Handlebar
- Electra attitude
- Grips
- Custom
- Stem
- Threadless 4-bolt
- Headset
- 1 1/8" steel threadless
- Brakeset
- Front/rear: Tektro hydraulic disc brakes
- Rotor size
- Front/rear: 180mm
Accessories
- Battery
- Bosch PowerPack 400, includes 4 AMP charger
- Controller
- Bosch Purion
- Motor
- Bosch Performance Line, 250 watts
- Front light
- Spanninga LED
- Rear light
- Spanninga LED
- Kickstand
- Alloy double leg
- Extras
- Reflective battery decal, painted chainguard, internal cable routing, and stainless steel and anti-rust hardware
Weight
- Weight
- 28.18 kg / 62 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
