Features
Compliant with leading safety regulations
The e-systems on Trek and Electra e-bikes are third-party tested to meet the latest e-bike safety regulations, including the stringent UL 2849 certification��so all you have to worry about is where your e-bike will take you next.
Specs
Frameset
- Frame
- 6061-T6 aluminum w/patented Flat Foot Technology
- Fork
- Hi-ten steel unicrown, straight/tapered leg
Wheels
- Front hub
- Alloy low-flange w/6-bolt disc, 36h, nutted
- Rear hub
- Hyena hub motor w/6-bolt disc, 36h, nutted
- Rims
- Anodized alloy 26"x36h
- Tires
- 26x2.35" balloon
Drivetrain
- Crank
- Forged alloy 170mm, 42t chainring
- Bottom bracket
- Hyena T47 w/integrated torque and cadence sensor
- Cassette
- 16t freewheel
- Chain
- KMC S1
- Pedals
- Resin platform w/non-slip rubber tread
Components
- Saddle
- Ergonomic w/shock-absorbing elastomers
- Seatpost
- Alloy straight post 27.2x400mm
- Handlebar
- Electra caf茅
- Grips
- Comfort kraton
- Stem
- Forged alloy 25.4mm quill, 80mm extension
- Headset
- 1 1/8" steel threaded/semi-integrated
- Brakeset
- Front/rear: mechanical disc brakes
- Rotor size
- Front/rear: 180mm
Accessories
- Battery
- Hyena 250Wh, includes 2 AMP charger
- Controller
- Hyena LED
- Motor
- Hyena rear hub motor, 250 watts
- Kickstand
- Alloy
- Extras
- Painted chainguard, internal cable routing, anti-rust hardware
Weight
- Weight
- 20.00 kg / 44.1 lbs
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
